At W. Rietveld Ltd. we move a lot of stock. If you can't find what you are looking for, contact us - we probably have it in one of our two yards.
We have over 4 hectares of land and dry storage.
Not everything is listed here.
If you have a project you are working on, drop in or Phone +64 3 453 6650
We are Otago's largest recycled machinery dealer
Our main focus these days is industrial machinery - both second hand, and new surplus
12" Green Silicon Carbide Grindstone Wheels
I have a few in stock of these new green silicon carbide grindstone wheels. Used for sharpening and shaping carbide tipped tooling
The stone is made by Brave Abrasives. They have a tapper grinding edge. The centre hole is 1 1/4" diameter.
It says max 2070rpm
They have the number 132 printed on them, it could be a model number or a grit number.
It says max 2070rpm
They have the number 132 printed on them, it could be a model number or a grit number.
12" (305mm) diameter x 2 1/2" (63.5mm)thick
kg
OTIS GeN2-MRL Complete Elevator (NEW)
Brand New GeN2-MRL lift supplied by OTIS Elevators.
We have one of these available.
This lift was purchased in 2014 for a building, but was never installed.
This lift has always been stored inside. This is all still in the original packing crates which have never been opened.
Below are the specs we have for this lift.
Type: GeN2-MRL
Duty Load: 1150kg
Speed: 1 m/s
Roping: 2:1
Type of Motor: 0
Control: VVVF
Operation: Automatic
Rise: 17,980mm
Number of Stops/Openings: 6/7
Min Floor Height: 2500mm
Type of Door: TLD
Door Opening: 900mm
System Normal Power: 17.8Kw
System Starting Current: 27.95 Amps
System Normal Current: 17.14 Amps
Heat Release: 3.2 kJ/s
Maximum Cable Size Required: 16mm
Extra Weight for Local Decoration: 400kg
This lift was purchased in 2014 for a building, but was never installed.
This lift has always been stored inside. This is all still in the original packing crates which have never been opened.
Below are the specs we have for this lift.
Type: GeN2-MRL
Duty Load: 1150kg
Speed: 1 m/s
Roping: 2:1
Type of Motor: 0
Control: VVVF
Operation: Automatic
Rise: 17,980mm
Number of Stops/Openings: 6/7
Min Floor Height: 2500mm
Type of Door: TLD
Door Opening: 900mm
System Normal Power: 17.8Kw
System Starting Current: 27.95 Amps
System Normal Current: 17.14 Amps
Heat Release: 3.2 kJ/s
Maximum Cable Size Required: 16mm
Extra Weight for Local Decoration: 400kg
L x W x H (mm)
kg
Large Hydraulic Bailing Press
Large Hydraulic Bailing Press
We have one of these available.
Hydraulic oil tank is 1.1m x 1.2m x 600mm high (about 800L max tank) the oil level is low but there was enough over the tank outlet so the press could be run up.
The large pusher cylinder is about 200-210mm dia bore x 2.7m stroke
The smaller pusher cylinder is about 200-210mm dia bore x 980mm stroke
The main chamber (first stage) is 900mm wide x 700mm high and 2.7m long, it takes about 35 seconds to fully extend the pusher and about 20 seconds to retract fully, the inlet hopper has an opening of 1980mm x 920mm
The exit chamber is 700mm wide x 700mm high and 980mm long, it has an extension section that can be bolted on that is 700mm long, it takes the pusher about 13 seconds to extend and about 7 seconds to retract.
The electrical components will need some attention, (We were able to run the individual parts of the system manually to test everything was working on the press and the speed things travelled.)
The limit switches for the exit section are not connected so are not working, I would recommend upgrading the old system to something more reliable, It wouldn’t hurt upgrading some of the switch board too. Best to get your electrician to look over this.
I estimate the weight around the 4.5 ton mark.
Hydraulic oil tank is 1.1m x 1.2m x 600mm high (about 800L max tank) the oil level is low but there was enough over the tank outlet so the press could be run up.
The large pusher cylinder is about 200-210mm dia bore x 2.7m stroke
The smaller pusher cylinder is about 200-210mm dia bore x 980mm stroke
The main chamber (first stage) is 900mm wide x 700mm high and 2.7m long, it takes about 35 seconds to fully extend the pusher and about 20 seconds to retract fully, the inlet hopper has an opening of 1980mm x 920mm
The exit chamber is 700mm wide x 700mm high and 980mm long, it has an extension section that can be bolted on that is 700mm long, it takes the pusher about 13 seconds to extend and about 7 seconds to retract.
The electrical components will need some attention, (We were able to run the individual parts of the system manually to test everything was working on the press and the speed things travelled.)
The limit switches for the exit section are not connected so are not working, I would recommend upgrading the old system to something more reliable, It wouldn’t hurt upgrading some of the switch board too. Best to get your electrician to look over this.
I estimate the weight around the 4.5 ton mark.
WAS $5300.00 + GST NOW $4500.00 + GST
7.1m L x 2.7m W x 2.15m H (mm) excludes the exit extension.
4500kg
11kw Varisco self priming Centrifugal Pump
11kw Varisco self priming centrifugal pump. 2" bsp in/out ports
Type: 10009704 EP J60-220 TWGW C3
11kw 2900rpm 3phase electric motor. The pump was made in 2008, its ratings are: 43m3/h(max) 59m head(max) 2900rpm(max) The pump has flap non return valve on intake port.
The pump has open impeller allowing the passage of solids of large diameter. High resistance to abrasive liquids: muddy, sandy waters with solids in suspension.
700 L x 420 W x 400 H (mm)
kg
